Details:
- Warrantyno
- Product Name: D775 Motor (DC 12V-36V 13000-19000 RPM High Torque & High Power Motor)
- Model: 775
- Shaft Diameter: 5mm
- Shaft length: 17mm
- Body length: 66.7mm
- Front steps diameter: 17.4 mm
- Former high level: 4.7 mm
- Body diameter: 42 mm
- Motor Overall Length: 98 mm
- Diagonal installation pitch: 28.8 mm
- Mounting hole size: M4
- Mounting hole: 2
- Torque: 2kg.cm or 0.2N.M
- Power Supply: DC 12V 5A - 36V 3A
- No load speed: 13000 RPM / 12v(rpm) Rated output power 75W
DC 775 Motor 12v-18V High Speed Motor Original
450 BDT599 BDTSave 149 BDT
Total sold : 453
Details:
- Warrantyno
- Product Name: D775 Motor (DC 12V-36V 13000-19000 RPM High Torque & High Power Motor)
- Model: 775
- Shaft Diameter: 5mm
- Shaft length: 17mm
- Body length: 66.7mm
- Front steps diameter: 17.4 mm
- Former high level: 4.7 mm
- Body diameter: 42 mm
- Motor Overall Length: 98 mm
- Diagonal installation pitch: 28.8 mm
- Mounting hole size: M4
- Mounting hole: 2
- Torque: 2kg.cm or 0.2N.M
- Power Supply: DC 12V 5A - 36V 3A
- No load speed: 13000 RPM / 12v(rpm) Rated output power 75W
