DC 775 Motor 12v-18V high speed motor original

Inva Gadget

DC 775 Motor 12v-18V high speed motor original
  • DC 775 Motor 12v-18V high speed motor original_img_0

DC 775 Motor 12v-18V high speed motor original

450 BDT599 BDTSave 149 BDT
sold_units 453
1

Details:

  • Warranty
    no

  1. Product Name: D775 Motor (DC 12V-36V 13000-19000 RPM High Torque & High Power Motor)
  2. Model: 775
  3. Shaft Diameter: 5mm
  4. Shaft length: 17mm
  5. Body length: 66.7mm
  6. Front steps diameter: 17.4 mm
  7. Former high level: 4.7 mm
  8. Body diameter: 42 mm
  9. Motor Overall Length: 98 mm
  10. Diagonal installation pitch: 28.8 mm
  11. Mounting hole size: M4
  12. Mounting hole: 2
  13. Torque: 2kg.cm or 0.2N.M
  14. Power Supply: DC 12V 5A - 36V 3A
  15. No load speed: 13000 RPM / 12v(rpm) Rated output power 75W
